Product Type:
Wash basin mixer with infrared sensor
Areas of Application:
Housekeeping, offices, personal sanitary facilities
Features / Components:
- electronic two-handle and touchless kitchen faucet
- adjustment of the flow rate of cold and hot water with separate handles
- swivel range of the spout 120 degrees
- orientation of the touchless faucet can be determined during installation
- is switched on by bringing the hands into the sensor's sensing range
- preset values for the sensing range / flow time can be changed on site
- water temperature is set on the mixer unit, which is mounted under the sink
- electrical connection is made using a 230/12 V plug-in transformer
- connection hoses: Diameter 10 x 600 (2 pieces) between mixer unit and angle valve
Technical Data:
- Working pressure: 100 to 1000 kPa
- Flow rate at 300 kPa: 0.21 l/s
- Temperature: maximum 80 degrees Celsius
- Electrical connection: 230/12 VAC
- Maximum flow time (non-contact function): 40 s
- sensor range (non-contact function): 2 cm (0 to 6 cm)
- follow-up time (non-contact function): 3 s (1 to 10 s)
- pressure loss at a flow rate of 0.2 l/s: 272 kPa
Price (without guarantee):
Price is available on request from the manufacturer / distributor.
