Product Type:
Drive unit for wheelchairs with direct drive
Description:
The retrofittable drive has two electric motors that engage in sprockets via extendable pinions and can be operated via a radio-controlled joystick. The drive is engaged and disengaged pneumatically.
Technical Data:
Total weight: 200 kg (person, wheelchair and max-e)
Attachment possible from seat width: 28 cm
Speed: Smoothly adjustable
forwards / backwards: 6 km/h / 3 km/h
Range with one battery charge: up to 16 km
Max. possible incline: up to 20 %
Height/width/depth: 28 / 34.5 / 14.5 cm
Wheel size: 20 / 24 inches
Batteries: 2 X 12 Volt / 16 Ah
DC motor: 2 X 24 V
Weight battery pack: 10.1 kg
Total weight: 20.1 kg
Weight control unit: 0.4 kg
Options / Accessories:
- various joystick options (e. g.E.g. with tetra fork or palm control)
- Bracket for attendant control
- Tilt supports
- Spoke protectors
- Support arm,
Price (without guarantee):
The price is available on request from the manufacturer/distributor.
